Carbon fiber sheets (plates) – Black and various colors (silk thread):
1. Thickness: 0.2mm, 0.25mm, 0.35mm, 0.6mm, 1.0mm, 1.5mm, 2.0mm to 50mm;
2. Sizes: 1000*1000mm, 1000*600mm, 500*500mm, 400*500mm;
3. Colors: Black, Gold + Gold Thread (Silver Thread), Blue + Silver Thread (Gold Thread), Green + Silver Thread, Silver + Silver Thread, Red + Red Thread (Silver Thread);
4. Textures: 1K, 1.5K, 3K, 6K, 12K plain weave and twill weave;
5. Good surface smoothness and gloss, average thickness (error ±0.05-±0.1), high strength, can be produced according to requirements.
Carbon Fiber Sheet/Plates Specification |
||
Item |
Dimension |
Thickness |
| Carbon Fiber Sheet/Plates | 400×500 mm | From 0.2mm to 50mm |
| 500×500 mm | ||
| 500×600 mm | ||
| 500×700mm | ||
| 500×1000mm | ||
| 1000×1000 mm | ||
| 1000×1200 mm | ||
| 1200×1200 mm | ||
| 1000×1400 mm | ||
| 1000×1500 mm | ||
| 1000×2000 mm | ||
| 1000×5000 mm | ||
| 1000×10000 mm | ||
| 3000×9000 mm | ||
