Carbon Fiber Tube Specification

carbon fiber tube

Can’t find what you are looking for?

Request a Quote

Carbon Fiber Tube Sizes Chart

2.8*4 mm 29.4*31 mm
3.0*5 mm 30*32 mm
3.2*5 mm 30.3*32 mm
3.6*5 mm 31*33 mm
4.0*6 mm 31.6*33 mm
5.0*7 mm 32*34 mm
5.5*7 mm 33*35 mm
6.0*8 mm 33.8*35 mm
7.0*9 mm 34*36 mm
7.2*9 mm 35*37 mm
7.5*10 mm 36*38 mm
8*10 mm 37*39 mm
9* 10.7 mm 37.2*39 mm
10*12 mm 38*40 mm
10.7*12.7 mm 39*41 mm
11*12.7 mm 39.6*42 mm
12*14 mm 40*42 mm
12.7*14 mm 41*43 mm
13*14.2 mm 42*44 mm
14*16 mm 43*45 mm
14*16.3 mm 44*46 mm
15*16.3 mm 45*47 mm
16*18 mm 46*48 mm
17*18.4 mm 47*50 mm
18*20 mm 48*50 mm
18.4*20 mm 50*55.15 mm
19*21 mm 55*57 mm
20*22 mm 55.15*57 mm
20.5*22 mm 56*60 mm
21*22.2 mm 57*60 mm
22.2*24 mm 60*68 mm
23.3*25 mm 70*73 mm
24*26 mm 73*75 mm
24*26.5 mm 75*86 mm
25*27 mm 85.5*87 mm
26.4*28 mm 86*90 mm
26.8*28 mm 87*90 mm
27*29 mm 90*107 mm
28*30 mm 107*110 mm
28.6*30 mm 29*31 mm
Remark:

1. The ID Could fit any OD listed Above.

2. Length Max Could be 3.5 Meters

3. The List will be continue when we making new molds……..

Carbon Fiber Tube More Details

  • Size: Any Size Make-to-Order
  • Appearance: 1K, 3K, 6K, 12K, 24K carbon fiber fabric
  • Shape.: Round, Square, Oval or per your request
  • Process: Molding, Vacuum, handcraft, RTM and etc.
  • Package- Just as your requirement.
  • Thickness: 0.5mm-50mm
  • Color: black or customized
  • Length:  30~3500mm and customize are available
  • Outer diameter:   4~300mm, customize are available
  • Tolerance :   +0.01mm or customized
  • Surface: Glossy/ Matte & Weave Pattern : Twill / Plain / UD
  • Material: 100% Carbon Fiber, Not including of any Glassfiber Mix Carbon.

OEM/ODM Service

OEM/ODM Service is available, According to customers design, the drawing (PDF & DWG & DXF & STP & IGS Format) customized Carbon Fiber Parts for RC Helicopter, RC cars, UAV Drone frame, Carbon fiber tubes and other carbon fiber products.

Good Price, Delivery Time and Best Services for Pre-delivery inspection & After-sales

Pre-Sale consultation

  • Timely delivery
  • Offer testing report

After-sale service

  • Immediate check of shipping status
  • Guide on the use of products properly

Our Business Scope

  • Sell quality design & fabrication Products worldwide
  • R&D advanced Carbon Fiber Products for brand owner
  • Manufacturer OEM carbon fiber products with high standard and high Modulus
  • Provide rapid prototype service according to drawings

Production Range

Aviation Industry

  • aircraft, plane main wing, empennage, and body, etc.

Marine

  • skis, kayaks, paddles, oars, canoes, etc.

Sporting Goods

  • Umbrella stand, tool handle, kites, bicycle frames, snowboards, skateboards, hockey and lacrosse shafts, golf clubs, etc

Aftermarket Car Parts

  • auto engine, synchronizer, machine covers, spoilers, bumpers, trim and so on.

Other Applications

  • Leather goods, pens, notebooks, jewelry, furniture, faucets, various models, building reinforcing, watches, pens, bags, gears, blankets, rotor blades, etc.
