Carbon Fiber 3D Printing

Carbon fiber 3D printing combines advanced additive manufacturing with high-performance composite materials, delivering exceptional strength-to-weight ratios unmatched by traditional manufacturing methods. Our proprietary process reinforces thermoplastic matrices (PA, PEEK, PEKK) with continuous or chopped carbon fibers, achieving mechanical properties comparable to aerospace-grade aluminum at 50% reduced weight.

Superior Mechanical Performance

  • Tensile strength: 180-210 MPa

  • Stiffness: 20-30 GPa

  • Impact resistance 5-8x higher than standard 3D prints

Weight Optimization

  • Material density: 1.4-1.6 g/cm³

  • Achieves 40-60% weight reduction vs. metal components

Thermal & Chemical Stability

  • Continuous service temperature: 150-300°C (depending on matrix)

  • Excellent resistance to fuels, lubricants, and industrial chemicals
